Black Boost Curved LED Bar

Name: Black Boost Curved LED Bar
Brand: Purelux
SKU: C56056200

SKU: S56056200

The Black Boost Curved Bar is a high-performance LED bar, available in 56 cm, 82 cm, 107 cm, and 127 cm.

Equipped with dual filament and minimum function in amber and/or white, it offers power, versatility, and a modern look for any type of vehicle.

Information Request

The Black Boost Curved Bar was developed to provide maximum visibility and performance in any situation. Available in lengths of 56 cm, 82 cm, 107 cm, and 127 cm, it easily adapts to different types of vehicles, from 4x4s and SUVs to commercial and work vehicles.

Equipped with a dual filament system, it allows you to switch between different levels of light intensity, ensuring greater flexibility of use. It also includes a low beam function with amber and/or white lighting, ideal for enhancing the vehicle's visual presence and increasing safety on the road.

With a powerful and uniform light beam, it ensures excellent range and wide coverage, significantly improving visibility when driving at night or in adverse conditions. Its robust construction is designed to withstand vibrations, dust, and bad weather, making it a reliable solution for demanding use, both on and off-road.

It combines technology, resistance, and modern design in a single piece of equipment, making it the ideal choice for those looking for additional lighting with professional performance and distinctive aesthetics.

Reference S56056200

Data sheet

Product Type: LED Lightbars
Vehicle Type (Compatibility): Universal

No customer reviews for the moment.

Brand and Model: Black Boost C820 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Calculated Power: 300 W

Power Consumption:

Purelux PowerBoost®: 20.66 A @ 12 V / 10.33 A @ 24 V
Road Mode: 10.16 A @ 12 V / 5.08 A @ 24 V

Power:

Purelux PowerBoost®: 248 W @ 24 V
Road Traffic Mode: 122 W @ 24 V

Light Output Declared by Manufacturer: 25200 lm (Purelux PowerBoost®)

Range:

576 m @ 1 lux / 1152 m @ 0.25 lux (Purelux PowerBoost®)
385 m @ 1 lux / 770 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End legs, width-adjustable lower legs
Connector: DTP-2
Parking lights + wires are separate
Cable Length: 50 cm
Dimensions: 814.9 × 70 × 78.6 mm (Width × Height × Depth)
Height with End Legs: 86 mm
Height with Lower Legs: 89 mm
Weight: 3200 g
Radius of Curvature: 2839 mm
IP Rating: IP69K
Approvals: ECE: R10, R148, R149*
*Road traffic approval does not apply to PowerBoost® mode

Brand and Model: Black Boost C1070 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating Voltage: 9–32 V
Calculated Power: 400 W

Power Consumption:

Purelux PowerBoost®: 29.75 A @ 12 V / 14.875 A @ 24 V
Road Mode: 14.5 A @ 12 V / 7.25 A @ 24 V

Power:

Purelux PowerBoost®: 357 W @ 24 V
Road Traffic Mode: 174 W @ 24 V

Light Output Declared by Manufacturer: 33600 lm (Purelux PowerBoost®)

Range:

580 m @ 1 lux / 1160 m @ 0.25 lux (Purelux PowerBoost®)
397 m @ 1 lux / 794 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End legs, width-adjustable lower legs
Connector: Straight wires, no connector
Parking lights + wires are separate
Cable Length: 50 cm
Dimensions: 1068.7 × 70 × 78.6 mm (Width × Height × Depth)
Height with End Legs: 86 mm
Height with Lower Legs: 89 mm
Weight: 4400 g
Radius of Curvature: 2839 mm
IP Rating: IP69K
Approvals: ECE: R10, R148, R149*
*Road traffic approval does not apply to PowerBoost® mode

Brand and Model: Black Boost C1300 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating Voltage: 10–30 V
Calculated Power: 480 W

Power Consumption:

Purelux PowerBoost®: 16.95 A @ 24 V
Road Mode: 8.57 A @ 24 V

Power:

Purelux PowerBoost®: 406.8 W @ 24 V
Road Mode: 205.9 W @ 24 V

Light Output Declared by Manufacturer: 40320 lm (Purelux PowerBoost®)

Range:

601 m @ 1 lux / 1202 m @ 0.25 lux (Purelux PowerBoost®)
401 m @ 1 lux / 802 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End legs, width-adjustable lower legs
Connector: Straight wires, no connector
Parking lights + wires are separate
Cable Length: 50 cm
Dimensions: 1272 × 70 × 132 mm (Width × Height × Depth)
Height with End Legs: 86 mm
Height with Lower Legs: 89 mm
Weight: 5000 g
Radius of Curvature: 2839 mm
IP Rating: IP69K
Approvals: ECE: R10, R148, R149*
*Road traffic approval does not apply to PowerBoost® mode

Brand and Model: Black Boost C560 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating Voltage: 9–32 V
Calculated Power: 200 W

Power Consumption:

Purelux PowerBoost®: 14.625 A @ 12 V / 7.31 A @ 24 V
Road Mode: 6.925 A @ 12 V / 3.45 A @ 24 V

Power:

Purelux PowerBoost®: 175.5 W @ 24 V
Road Mode: 83.1 W @ 24 V

Light Output Declared by Manufacturer: 16800 lm (Purelux PowerBoost®)

Range Measured by Valostore:

539 m @ 1 lux / 1078 m @ 0.25 lux (Purelux PowerBoost®)
372 m @ 1 lux / 744 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End legs, width-adjustable lower legs
Connector: DTP-2
Parking lights + wires are separate
Cable Length: 50 cm
Dimensions: 562.9 × 70 × 78.6 mm (Width × Height × Depth)
Height with End Legs: 86 mm
Height with Lower Legs: 89 mm
Weight: 2300 g
Radius of Curvature: 2839 mm
IP Rating: IP69K
Approvals: ECE: R10, R148, R149*
*Road traffic approval does not apply to PowerBoost® mode
