X-Slim LED Bar

Name: X-Slim LED Bar
Brand: Purelux
SKU: S2002060

SKU: S1801824

The X-Slim Light Bar is a high-performance LED light bar, available in 18 cm, 25 cm, 52 cm, 80 cm, 100 cm and 128 cm sizes.

Equipped with a single visible filament, it offers power, an ultra-slim design, versatility and a modern look for any type of vehicle. All sizes, except the 18 cm version, include amber and/or white position light function.

Information Request

The X-Slim Light Bar was developed to deliver maximum visibility and performance in any situation. Available in 18 cm, 25 cm, 52 cm, 80 cm, 100 cm and 128 cm lengths, it easily adapts to different types of vehicles, from 4x4s and SUVs to commercial and work vehicles.

Equipped with a single visible filament, it provides consistent and efficient lighting, ensuring simple and reliable operation in any context. It also includes an amber and/or white position light function in all sizes except the 18 cm version, helping to enhance the vehicle’s visual presence and improve road safety.

With a powerful and uniform light beam, it ensures excellent range and wide coverage, significantly improving visibility during night driving or in adverse conditions. Its ultra-slim and robust construction is designed to withstand vibrations, dust and harsh weather, making it a reliable solution for demanding use both on-road and off-road.

It combines technology, minimalist design and durability in a single unit, making it the ideal choice for those seeking additional lighting with professional performance and a modern, distinctive aesthetic.

Reference S1801824

Data sheet

Product Type: LED Lightbars
Vehicle Type (Compatibility): Universal

No customer reviews for the moment.

Brand and Model: Purelux Black X-Slim S250 Gen2
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating Voltage: 9–32 V
Calculated Power: 45 W

Consumption:
Purelux PowerBoost®: 3.16 A @ 12 V / 0.91 A @ 24 V
Road Mode: 1.83 A @ 12 V / 0.91 A @ 24 V

Power:
Purelux PowerBoost®: 37.9 W @ 24 V
Road Mode: 22 W @ 24 V

Light Output Declared by Manufacturer: 3780 lm (Purelux PowerBoost®)

Range:
370 m @ 1 lux / 740 m @ 0.25 lux (Purelux PowerBoost®)
282 m @ 1 lux / 564 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End feet, width-adjustable lower feet
Connector: DT-2
Cable Length: 50 cm
Dimensions: 246 × 40 × 54 mm (Width × Height × Depth)
Height with End Feet: 49 mm
Height with Lower Feet: 51 mm
Weight: 700 g
IP Rating: IP69K
Approvals: ECE: R10, R148, R149*

Road traffic approval does not apply to PowerBoost® mode

Brand and model: Purelux Black X-Slim S520 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating voltage: 9–32 V
Calculated power: 105 W

Consumption:
Purelux PowerBoost®: 7.36 A @ 12 V / 3.68 A @ 24 V
Road mode: 4.24 A @ 12 V / 2.12 A @ 24 V

Power:
Purelux PowerBoost®: 88.3 W @ 24 V
Road mode: 50.9 W @ 24 V

Light output declared by manufacturer: 8820 lm (Purelux PowerBoost®)

Range:
545 m @ 1 lux / 1090 m @ 0.25 lux (Purelux PowerBoost®)
410 m @ 1 lux / 820 m @ 0.25 lux (Traffic mode)

Color temperature declared by manufacturer: 5700 K

Mounting: End feet, width-adjustable lower feet
Connector: DT-2
Cable length: 50 cm
Dimensions: 522 × 40 × 54 mm (Width × Height × Depth)
Height with end feet: 49 mm
Height with lower feet: 51 mm
Weight: 1360 g
IP rating: IP69K
Approvals: ECE: R10, R148, R149*

Road traffic approval does not apply to PowerBoost® mode

Brand and model: Purelux Black X-Slim S800 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating voltage: 9–32 V
Calculated power: 165 W

Consumption:
Purelux PowerBoost®: 11.75 A @ 12 V / 5.875 A @ 24 V
Road mode: 6.8 A @ 12 V / 3.4 A @ 24 V

Power:
Purelux PowerBoost®: 141 W @ 24 V
Road mode: 81.6 W @ 24 V

Light output declared by manufacturer: 13860 lm (Purelux PowerBoost®)

Range:
564 m @ 1 lux / 1128 m @ 0.25 lux (Purelux PowerBoost®)
428 m @ 1 lux / 856 m @ 0.25 lux (Traffic mode)

Color temperature declared by manufacturer: 5700 K

Mounting: End feet, width-adjustable lower feet
Connector: DT-2
Cable length: 50 cm
Dimensions: 798 × 40 × 54 mm (Width × Height × Depth)
Height with end feet: 49 mm
Height with lower feet: 51 mm
Weight: 2100 g
IP rating: IP69K
Approvals: ECE: R10, R148, R149*

Road traffic approval does not apply to PowerBoost® mode

Brand and model: Purelux Black X-Slim S1000 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating voltage: 9–32 V
Calculated power: 210 W

Consumption:
Purelux PowerBoost®: 15 A @ 12 V / 7.5 A @ 24 V
Road mode: 8.75 A @ 12 V / 4.375 A @ 24 V

Power:
Purelux PowerBoost®: 180.1 W @ 24 V
Road mode: 105 W @ 24 V

Light output declared by manufacturer: 17640 lm (Purelux PowerBoost®)

Range:
556 m @ 1 lux / 1112 m @ 0.25 lux (Purelux PowerBoost®)
422 m @ 1 lux / 844 m @ 0.25 lux (Traffic mode)

Color temperature declared by manufacturer: 5700 K

Mounting: End feet, width-adjustable lower feet
Connector: DT-2
Cable length: 50 cm
Dimensions: 1005 × 40 × 54 mm (Width × Height × Depth)
Height with end feet: 49 mm
Height with lower feet: 51 mm
Weight: 2700 g
IP rating: IP69K
Approvals: ECE: R10, R148, R149*

Road traffic approval does not apply to PowerBoost® mode

Brand and model: Purelux Black X-Slim S1300 Gen3
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating voltage: 10–30 V
Calculated power: 270 W

Consumption:
Purelux PowerBoost®: 9.42 A @ 24 V
Road mode: 5.51 A @ 24 V

Power:
Purelux PowerBoost®: 226.1 W @ 24 V
Road mode: 132.4 W @ 24 V

Light output declared by manufacturer: 22680 lm (Purelux PowerBoost®)
Measured light output: 16940 lm (PowerBoost®) / 9785 lm (Road mode)

Range:
563 m @ 1 lux / 1126 m @ 0.25 lux (Purelux PowerBoost®)
429 m @ 1 lux / 858 m @ 0.25 lux (Traffic mode)

Color temperature declared by manufacturer: 5700 K
Measured color temperature: 5704 K

Mounting: End feet, width-adjustable lower feet
Connector: DTP-2
Cable length: 70 cm
Dimensions: 1281 × 40 × 54.4 mm (Width × Height × Depth)
Height with end feet: 49 mm
Height with lower feet: 51 mm
Weight: 3300 g
IP rating: IP69K
Approvals: ECE: R10, R148, R149*

Road traffic approval does not apply to PowerBoost® mode

Brand and Model: Purelux Black X-Slim S180 Gen2
Purpose: As an additional light for cars / off-road vehicles / work machines
LED: Osram
Operating Voltage: 9–32 V
Calculated Power: 24 W

Consumption:
Purelux PowerBoost®: 2.00 A @ 12 V / 1.00 A @ 24 V
Road Mode: 1.00 A @ 12 V / 0.50 A @ 24 V

Power:
Purelux PowerBoost®: 24 W @ 24 V
Road Mode: 12 W @ 24 V

Light Output Declared by Manufacturer: 1751 lm (Purelux PowerBoost®)

Range:
330 m @ 1 lux / 660 m @ 0.25 lux (Purelux PowerBoost®)
235 m @ 1 lux / 470 m @ 0.25 lux (Traffic Mode)

Color Temperature Declared by Manufacturer: 5700 K

Mounting: End feet, width-adjustable lower feet
Connector: DT-2
Cable Length: 50 cm
Dimensions: 180 × 70 × 67 mm (Width × Height × Depth)
Height with End Feet: 86 mm
Height with Lower Feet: 89 mm
Weight: 800 g
IP Rating: IP69K
Approvals: ECE: R10, R112*

Road traffic approval does not apply to PowerBoost® mode

The Purelux Black X-Slim S250 Gen2 LED Bar (25 cm) offers 45 W of power with Osram LEDs, producing up to 3780 lm in PowerBoost® mode.

With an ultra-slim design and a single visible filament, it provides compact and high-performance lighting for cars, off-road vehicles, and work machines, ensuring a modern, efficient, and versatile solution.

It includes white and/or amber position light function, enhancing visibility and road presence.

The Purelux Black X-Slim S520 Gen3 LED Bar (52 cm) offers 105 W of power with Osram LEDs, producing up to 8820 lm in PowerBoost® mode.

It includes white and/or amber position light function, enhancing visibility and road presence.

The Purelux Black X-Slim S800 Gen3 LED Bar (80 cm) offers 165 W of power with Osram LEDs, producing up to 13860 lm in PowerBoost® mode.

It includes white and/or amber position light function, enhancing visibility and road presence.

The Purelux Black X-Slim S1000 Gen3 LED Bar (100 cm) offers 210 W of power with Osram LEDs, producing up to 17640 lm in PowerBoost® mode.

It includes white and/or amber position light function, enhancing visibility and road presence.

The Purelux Black X-Slim S1300 Gen3 LED Bar (128 cm) offers 270 W of power with Osram LEDs, producing up to 22680 lm in PowerBoost® mode.

With an ultra-slim design and a single visible filament, it delivers powerful and uniform lighting for cars, off-road vehicles, and work machines, ensuring high performance, durability, and a modern design.

It includes white and/or amber position light function, enhancing visibility and vehicle presence.

The Purelux Black X-Slim S180 Gen2 LED Bar (18 cm) offers 24 W of power with Osram LEDs, producing up to 1751 lm in PowerBoost® mode.

With an ultra-slim design and a single visible filament, it provides compact and high-performance lighting for cars, off-road vehicles, and work machines, making it ideal for installations where space is limited.
